| Product name | Expanded Metal Mesh |
| Material | 304/316 stainless steel ,copper,bress |
| Mesh Size | 2 Mesh – 3500Mesh (standard) |
| Wire Diameter | 0.03mm – 3.0mm (customizable) |
| Free simple | Sample is available |
| Packaging | Jumbo bag and pallet |
| Payment method | T/T,LC, Western Union, PayPal, Escrow and Money Gram |
Expanded metal mesh is a unique and versatile metal product manufactured through a specialized process of cutting and stretching solid metal sheets. Unlike woven or welded meshes, it features a single, continuous piece of metal with a uniform pattern of diamond, square, or hexagonal openings, created without removing any material—just by rearranging the metal. This innovative production method results in a mesh that offers exceptional strength, durability, and structural integrity, making it a preferred choice for a wide range of industrial, commercial, architectural, and decorative applications.
Material Options
- Carbon Steel: A cost-effective option with high tensile strength, ideal for general industrial use, indoor applications, and structural purposes. It can be further treated with paint or galvanization for enhanced corrosion resistance.
- Galvanized Steel: Available in hot-dip galvanized and electro-galvanized options, this material provides excellent resistance to rust and corrosion, making it suitable for outdoor use, humid environments, and agricultural settings.
- Stainless Steel (304, 316): 304 stainless steel offers good corrosion resistance for most environments, while 316 stainless steel provides superior protection in harsh conditions such as marine environments, chemical processing facilities, and high-salt areas.
- Aluminum: Lightweight yet strong, aluminum expanded mesh is resistant to corrosion and ideal for applications where weight is a concern, such as aerospace components, architectural facades, and transportation equipment.
- Copper and Brass: These materials offer excellent electrical conductivity and a distinctive aesthetic appeal, making them suitable for decorative purposes, electrical components, and heat exchangers.
Structural Characteristics
- Patterns: Diamond (most common), square, hexagonal, and custom patterns.
- Opening Sizes: Ranging from small openings (3mm x 6mm) for fine filtration to large openings (100mm x 200mm) for heavy-duty applications.
- Sheet Thickness: 0.3mm to 10mm, depending on the material and intended use.
- Sheet Sizes: Standard sizes up to 2000mm x 3000mm, with custom sizes available upon request.
- Surface Treatments: Mill finish, galvanized, painted, powder-coated, polished, etc., to enhance corrosion resistance and appearance.
Applications
1. Architectural Sector
- Building facades and sunscreens
- Interior decorative panels
- Balustrades and stair treads
2. Industrial Uses
- Filtration systems (air/liquid)
- Machine guards and safety screens
- Conveyor belts and sorting screens
3. Specialty Applications
- Acoustic panels for noise control
- Agricultural equipment components
- Automotive grilles and vents
